Description
Muir Storm 3500 Low Profile 24V Windlass MSS3500R24E
The Muir Storm 3500 Low Profile Windlass is ideal for boats ranging from 48' - 77'. The Storm 3500 is driven by a 1500W motor. Since 1968, Muir has been an industry leader in anchoring systems worldwide designing systems suitable for luxury mega yachts, pleasure crafts, and commercial vessels. When you purchase a Muir Windlass you get an anchoring system that not only meets or exceeds your performance and safety standards but is also designed with a style and finish to enhance the aesthetics of your boat. With proper installation, maintenance, and operation your new Muir windlass will give you years of reliable performance.
Features of the Muir Storm 3500 MSS3500R24E:
- Dual Direction, Permanent Magnet Motor
- Stainless Worm Drive, Self-Aligning Radially Adjustable Gearbox
- 316 Stainless Steel Finish
- Bronze Gears
- Stainless Mainshaft
- Swiveling Chainpipe
- Chrome Chain Stripper with Stainless Steel Band
- Stainless Steel Studs, Washers, and Nuts
- Ideals for boats ranging from 48' - 77' (15-24m)
Specifications of the Muir Storm 3500 MSS3500R24E:
- 24V Low Profile Design
- 1500W Motor
- Power Rating 3500lbs
- Approximately 85 Amps Draw
- Approximately 85 Amps Work Load
- Max Load 3500lbs (1587kg)
- Work Load 875lbs (397kg)
- Max Retrieval Speed at 44ft/min.
- 5/16BBB or HT, 3/8BBB or HT, 1/2HT
- 9/16, 5/8, 3/4 in.
- Net weight 101lbs
- Max 60mm deck clearance (extra deck clearance available up to 6")
Includes:
- Footswitch
- Watertight Solenoid Box
- Clutch Handle
- MSS3500R24E Windlass
Why you should purchase your Muir Storm 3500 from Seatech Marine Products:
Here at Seatech Marine Products, we strive to provide our customers with the right equipment at the lowest prices available. Along with being your source for marine products online, we provide installation and repair services in San Diego, California. We are known for getting the job done right and providing solutions. Our expect staff is available to answer any questions you may have before and after purchasing your windlass.
Call us today if you have any questions (866) 456-1379
Downloads:
Muir Storm 3500 Owners Manual PDF
Rope Chain Management System (RCMS) Adjustment PDF
Muir Storm 3500 Parts Breakdown PDF
