KE551 Twin-Engine Electronic Control Kit — Chrome, Composite Trim/Tilt Levers

KE5+ · electronic shift and electronic throttle

The NHK MEC KE551 is a KE5+ electronic marine engine-control base kit for two engines and one helm station, with electronic shift and electronic throttle connections. The chrome control head has composite trim/tilt levers.

• Product type: Single-station base kit
• Engine configuration: two engines; electronic shift and electronic throttle
• Lever style: composite trim/tilt; chrome control head
• Order separately: Two bus-harness sections and any installation-specific engine-interface parts

Planning a replacement or upgrade?

Use the replacement link and the applicable manuals to compare the current system with the installed equipment. Matching engine count alone does not establish that control heads, control units or harnesses interchange between generations.

Legacy kit components

• 1 × NM1051-00 — Twin-Engine KE+ Control Head - Chrome - Composite Levers with Trim/Tilt
• 2 × NM2406-00 — Control Unit 12/24v
• 2 × NM0640-10 — Shift Harness - 10 Meter
• 2 × NM0666-10 — Throttle Harness - 10 Meter
• 1 × NM0647-09 — KE+/XG T-Harness (R/C-1) with Terminator
• 1 × NM0647-12 — KE+/XG T-Harness (Port) with Terminator
• 1 × NM0647-13 — KE+/XG T-Harness (STBD)
• 1 × NJ0772-00 — Trim Circuit Harness - KE+/XG
• 4 × NM0414-28 — Power Harness, 5 m
• 1 × control-head buzzer: NJ0251-00 for 12 V or NJ0515-00 for 24 V

Required separately and installation planning

• NM0649 bus harnesses — select two sections for the standard twin-engine, single-station layout. Confirm each route length against the applicable wiring diagram. Bus, power and engine-interface harnesses have different roles.
• Match the electronic shift and throttle output settings and engine-side connections to the engine and gearbox. This electronic/electronic configuration does not use a mechanical shift/throttle actuator or require the two push-pull cables used by KE4XG.
• Configure the system using the control-unit settings described in the applicable legacy manual. Do not apply KE-XG programming instructions to a different generation.
• The listed power harnesses are 5m. Optional 10m power harnesses can be discussed when requesting the complete system quote.

Request complete system pricing to include the required harnesses, cables and other installation parts.

Station expansion and setup options

KE5+ supports up to four helm control heads plus one optional wired handheld station with the appropriate components.

• KE551A — matching additional-station kit
• NM0906-00 — optional wired twin-engine handheld remote; match the socket harness and system generation.

Planning a wireless docking remote? Ask Seatech to confirm the remote model, compatible control-system interface and additional hardware before ordering.

Dimensions and reference images

View the linked map

KE5+ technical specifications

• Supply voltage: 9-31 V DC
• Shift output: Coupled to the supply voltage; forward, reverse and neutral connections; 9 A maximum
• Throttle current output: 4-20 mA
• Throttle voltage output: 0.2-4.5 V
• Throttle PWM output: 6-94% duty cycle at 500 Hz
• Throttle CAN output: SAE J1939
• Idle-validation switch: Normally closed / normally open; 24 V, 2 A maximum
