Phasor Marine 7.0kW Permanent Magnet Diesel Boat Generator

(No reviews yet) Write a Review
SKU:
K3-7.0PMG
UPC:
K3-7.0KW PMG
Condition:
New
  • Phasor Marine 7.0kW Permanent Magnet Diesel Boat Generator
  • Phasor Marine 7.0kW Permanent Magnet Diesel Boat Generator
For pricing use the "Request Special Pricing" form below
Built to Order - Typical Lead Time is 30 Days

Description

PHASOR MARINE 7kW PERMANENT MAGNET DIESEL GENERATOR - K3-7.0PMG

The Phasor Marine 7.0Kw permanent magnet generator is one of the most popular marine diesel gensets for boats 25' - 50'. The unit outputs 58 amps on 120VAC at a low 1,800 RPM operating speed; powered by a Kubota 3 cylinder diesel engine. Units are built to order, typical lead time is 30 days.

To receive Special Pricing on this unit, please click on the Request Special Pricing form below.


Product Features:

  • Engine Features
    • Kubota Diesel Engine: D902-E4B - 3 Cylinder - 54 cu.in. displacement - Naturally Aspirated/IDI
    • Single Bearing Direct Coupled Generator
    • Safety shutdown system for high coolant temp or low oil pressure
    • Air Intake Cleaner / Silencer
    • Stainless Steel Exhaust Elbow Cast
    • Stainless Steel 4-Point isolation mounts
    • Belt Guard
    • Awl-Craft 2000 Urethane Finish - Long Lasting Gloss - Color Retention
    • IGNITION PROTECTED CERTIFIED
  • Electrical Features
    • +/- 1% Solid-state voltage regulation
    • Single series circuit control system with no printed circuit boards - tinned wiring
  • Fuel System Features
    • Electric Fuel Transfer Pump
    • Secondary 5 Micron Fuel Filter
    • USCG Approved fuel lines
    • Self Bleed Fuel System
  • Oil System Features
    • Spin-on lube filter
    • Forged Brass Oil Drain Valve with Safety Lock
  • Cooling System Features
    • Gear Driven Raw Water Pump
    • Molded blue silicone water hoses with Stainless Steel AWAB Clamps
    • Freshwater Double Pass Heat Exchanger - zinc anode inside

Product Specifications:

  • Dimensions
    • (LxWxH) 26.3"x 18.0"x 22.5"
    • w/ Hard Sound Enclosure 30"x23"x25.5"
  • Weight 344lbs
  • Electric End: Coliseum
  • Operating Speed: 1,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
  • Output Volts: 120/240
  • Output Amps: 58/29
  • Output Watts: 7,000
  • Phasor Marine 5 Year Limited Warranty

Optional upgrades:

  • Remote Panels
    • w/ 10 ft extension harness 101-0061
    • w/ 20 ft extension harness 101-0062
    • Remote Start/Stop W/O hour meter w/ 20ft harness 101-0092
    • Remote Start/Stop w/ Four Gauges and 20ft harness 101-0060
    • Relay Pak needs to be used with harnesses over 20ft 101-0333
  • Other Parts

Downloads & Resources:


View AllClose

Warranty Information

Seatech Marine Products is an authorized dealer for Phasor Generators. This part has a limited 5 year warranty from them. See below under downloads for full warranty information.
