Phasor Marine K3-8.5KW Standard Series Diesel Boat Generator

PHASOR MARINE 8.5kW Marine Diesel Generator - K3-8.5KW

The Phasor Marine 8.5Kw generator is one of the most popular marine diesel gensets for boats 25' - 45'. The unit outputs 70 amps on 120VAC at a low 1,800 RPM operating speed; powered by a Kubota D1005-E4BG 3 cylinder diesel engine.

To receive Special Pricing on this unit, please click on the Request Special Pricing form below.

Product Features:

• Engine Features
• Kubota Diesel Engine: D1005-E4BG - 3 Cylinder - 61.08cu.in. displacement - Naturally Aspirated/IDI
• Single Bearing Direct Coupled Brushless Generator
• Safety shutdown system for high coolant temp or low lube oil pressure
• Air Intake Cleaner / Silencer
• Stainless Steel Exhaust Elbow Cast
• Stainless Steel 4-Point isolation mounts
• Belt Guard
• Awl-Craft 2000 Urethane Finish - Long Lasting Gloss - Color Retention
• Electrical Features
• +/- 1% Solid-state voltage regulation
• Single series circuit control system with no printed circuit boards - tinned wiring
• Fuel System Features
• Electric Fuel Transfer Pump
• Secondary 5 Micron Fuel Filter
• USCG Approved fuel lines
• Self Bleed Fuel System
• Oil System Features
• Spin-on lube filter
• Forged Brass Oil Drain Valve with Safety Lock
• Cooling System Features
• Gear Driven Raw Water Pump
• Molded blue silicone water hoses with Stainless Steel AWAB Clamps
• Freshwater Double Pass Heat Exchanger - zinc anode inside

Product Specifications:

• Dimensions
• (LxWxH) 31.5"x 18.0"x 22.5"
• w/ Hard Sound Enclosure 34.5"x22"x25.5"
• Weight 567
• Electric End: Linz
• Operating Speed: 1,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
• Output Volts: 120/240
• Output Amps: 70/35
• Output Watts: 8,500
• Phasor Marine 5 Year Limited Warranty
