Description
SeaStar 31537 Pivot 40 Series
Brand: Dometic SeaStar Store SKU: 31537
Manufacturer reference: 031537
031537 is a pivot in the manufacturer’s 4300/43-series cable-connection table. Its drawing gives a 1/4-inch A dimension and a 7/8-inch overall E dimension. Use the lettered manufacturer drawing to compare the pivot with the existing connection.
Technical details
| Manufacturer cable family | 4300/43 |
|---|---|
| Drawing dimension A | 1/4 in |
| Drawing dimension B | 1/2 in |
| Drawing dimension C | 1/2 in |
| Drawing dimension D | 13/64 in |
| Drawing dimension E | 7/8 in |
Pivot 40 Series 031537
Manufacturer references and downloads
- Dometic Ride & Handling Catalog — 2022, Revision 04.15.22 (PDF)
Legacy manufacturer reference 031537. See PDF page 203 for the listed cable/control family and compare it with your installed system before ordering.
Warranty Information
Seatech Marine Products is an authorized dealer for Dometic that distributes SeaStar Products, this part has a 2 Year Limited Warranty from them. Please visit their website for full details: https://www.dometic.com/en-us/outdoor/support/warranty-statements
