Dometic Seastar
SeaStar HA6802 Twin Engine Single Cylinder Mounting Hardware
- SKU:
- HA6802
- Condition:
- New
Description
SeaStar HA6802 Twin Engine Single Cylinder Mounting Hardware
The Dometic Seastar HA6802 is the mounting hardware kit for Seastar Tournament Series Cylinders. Used on twin engine - single cylinder applications. Tournament Series are extreme heavy duty cylinders and tie bars designed for primarily high performance multiple engine applications, also available for single engine applications.
Features:
- Hardware kit for Seastar Tournament Series Cylinders
- Twin Engine - Single Cylinder only
- Heavy Duty construction
- Includes drive bracket
Specifications:
- Engines with Center to Center Distance of 25.7" - 30.6"
Downloads & Resources:
- SeaStar Tournament Series Cylinders Brochure [PDF]
- SeaStar Tournament Series Cylinders Data Sheet [PDF]
- SeaStar Tournament Series Cylinder Installation Manual [PDF]
- SeaStar Solutions Warranty [PDF]
- SeaStar Steering Catalog [PDF]
- SeaStar Hydraulic Steering Selection Guide [PDF]
- Dometic Seastar Hydraulic Build Guide [HERE]
Related Parts:
Seastar Tournament Mounting Hardware:
- Sing Engine - Single Cylinder: HA6801
- Twin Engine - Single Cylinder: HA6802
- Twin Engine - Dual Cylinder: HA6804
- Twin Engine - Dual Cylinder: HA6806
- Quad Engine - Dual Cylinder: HA6811
Seastar Tournament Tie Bars:
- Extra Small: HO6918
- Small: HO6820
- Medium: HO6821
- Large: HO6822
- Extra Large: HO6823
- Extra Extra Large: HO6824
Seastar Tournament Spare Parts:
- Elbow Fitting Service Kit: HF6004
- ORB Tee Fitting Kit: HF6005
- Gland Service Kit: HP6160
- Support Rod Service Kit: HP6161
- Support Bracket Service Kit: HP6162
Optional Seastar Parts:
- Seastar Tournament Cylinder: HC6845
- Seastar Helm Pumps: Helm Pumps
- Seastar Hose: Seastar Hose Kits
- Seastar Power Assist: Power Assist Systems
- Hydraulic Fluid: HA5430H or H5606
Notes:
- Installation may vary according to the following factors: engine mounting height, transom thickness, use of transom savers, tiller bolt hole location, engine tilt range, and engine size.
- For center engine drops greater than 3 inches (76mm), please consult SeaStar Solutions® Technical Service.
- Tie bar length may vary depending on toe in/toe out setup. To allow for toe, add or subtract from your nominal engine center to center distance.
- Based on recommended engine manufacturer minimum center to center distances. Deviating from these recommendations may require stroke limiting cylinders and/or engine tilt limiting, please consult SeaStar Solutions® Technical Service.
- Cylinder’s must be plumbed in parallel only, no series connections. Only exception is if cylinders are utilizing a liquid tie bar.
