Dometic Seastar
SeaStar HH6492-4 Sport Plus Tilt 2.4 Hydraulic Boat Helm Pump
- SKU:
- HH6492-4
- UPC:
- HH64924
- Condition:
- New
Description
SeaStar HH6492-4 Sport Plus Tilt 2.4 Hydraulic Boat Helm Pump
The world's most popular hydraulic boat steering helm (HH64924) offers smooth, efficient no feedback steering for inboard and outboard applications. Super-efficient steering for today’s high performance hulls with single or multiple outboards up to 700 HP combined. It’s the OEM Choice for center consoles, cruisers and more.
Important: SeaStar Helm Update to -4
The latest series of helms has been redesigned to provide a better experience for the vessel operator:
- New valve technology ensures tighter, quieter, and more responsive steering, while minimizing the potential for chattering when dealing with overrunning steering loads.
- More durable check valves, making the entire steering system more resilient to the rigors of trailering.
- Revamped Design to enhance their aesthetics, and has introduced a new fill port plug design for easier maintenance.
- HH6492-4 replaces the HH6492-3, HH6492 and is the direct replacement
Applications:
- Most Hydraulic Steering applications for inboard/sterndrive/outboard boats up to 50ft
- Single outboard engine boats that travel up to 55MPH, for boats over 55-60MPH see PRO Helm Pumps
- Capable to be used in multiple stations.
Features:
- Preloaded Dual Taper Bearings
- Smooth Operation and Feel
- 48 Degree Tilt Range
- 5 Positive Lock Positions
- Accepts Wheels up To 20"
- Maintenance Free
- 4.25 Turns Lock-To-Lock
- Compact Helm - Needs only 3" Dash Hole
- Warranty: Limited 2 Year
Specifications:
- Standard 3/4" Tapered Steering Shaft
- Front Mount Installation
- 2.4 Cubic Inches
- 1000 PSI Relief Valve Settings
Downloads & Resources:
- Sport & Sport Plus Instruction Manual
- SeaStar Boat Helm Installation Manual [PDF]
- SeaStar Hydraulic Steering Selection Guide [PDF]
- SeaStar Marine Steering Catalog [PDF]
- Dometic Seastar Hydraulic Build Guide [HERE]
- We can rebuild your HH6492-4 [HERE]
CAUTIONS:
- Do NOT use Teflon or Loctite on the fittings
- Do NOT try to install NPT fittings into helm pump as it may cause damage to the threads
- The fluid cap must be in the uppermost position at ALL times
- NEVER use brake fluid, only SeaStar Steering fluid or Mil Spec H5606 Fluid
Installation Notes:
- The helm pump is packaged with repositionable O-ring hose fittings (ORB)
- If a 20° mounting wedge is used, cut out dash as per mounting wedge template and mount helm directly to the 20° wedge
- The helm may be mounted with the helm shaft horizontal, vertical, or any angle in between
- Install the hose fittings before installing helm pump for ease of installation
Related Items & Spare Parts:
- HA5430H 1 Quart of SeaStar Fluid
- HA5438 Helm Bottle Filler Kit
- HP6032 Service Kit
- HF6004 Fittings
- HA5432 Non Vent Cap
- Seastar Hose
- Seastar Helm Pumps
- Seastar Cylinders
