Seastar HK4200A-3 Baystar Outboard Steering Kit 1.4 cu in. Helm Pump with Compact Cylinder

(No reviews yet) Write a Review
SKU:
HK4200A-3
UPC:
HK4200A3
DISCONTINUED (see below for options)

Description

BayStar Outboard Steering Kit - 1.4 cu in. Helm Pump with Compact Cylinder HK4200A-3

DISCONTINUED: ORDER THE HK4300-4 KIT HERE

Includes:

  • BayStar 1.4 cu in. Helm Pump HH4314-3
  • BayStar Compact Cylinder HC4645-3
  • BayStar Tubing Kit 2 x 20' Hoses (6.1 meters) HT4420H
  • 2 x StarStar Hydraulic Steering Fluid 32 fl. oz (1 liter) HA5430H
  • Bottle Filler Kit HA5438

Specifications:

  • Patented No FeedBack™ Steering lock valves
  • 5 turns lock-to-lock.
  • For systems up to 150 horsepower (total)
  • Fixed Cylinder
  • Requires 3" (76mm) cut-out hole in dash.
  • Requires 21" (534mm) splashwell width
  • DO NOT use BayStar on small HP outboard engines that use wing nut type transom mount clamping screws.

APPLICATION GUIDE

Use the following chart to identify if your system needs an additional part.

Cylinders HC4645H/47H/48H/58H)

MANUFACTURER YEAR MODEL CYLINDER NOTES
FORCE 1985–DATE 90–150 HP HC4645H
HONDA 1992–DATE 30–90 HP HC4645H
1998–2009 115–130 HP HC4647H
2001–DATE 150 HP HC4645H
2003–DATE BF135 HP HC4645H
2010–DATE 115–150 HP HC4645H
JOHNSON / EVINRUDE 1977–1989 65–150 HP HC4648H
1991–DATE 40–150 HP HC4645H
1997–DATE 115 HP FICHT HC4658H See Notes 4, 5
1997–DATE 75–150 HP FICHT HC4645H
1998–DATE 40–140 HP 4-Stroke HC4658H See Notes 1, 4
MERCURY/MARINER 1984–DATE 75–150 HP HC4645H
NISSAN 1990–DATE 120–140 HP HC4645H
SUZUKI 1986–DATE 150 HP HC4645H
1996 ONLY 115–140 HP N/A
1987–2002 115–140 HP HC4645H See Note 1
1990–2000 90–100 HP HC4645H
1998–DATE 40–70 4-Stroke HC4645H See Note 1
2001–DATE 115–140 HP 4-Stroke HC4658H See Notes 1, 4
TOHATSU 1990–DATE 40–140 HP HC4645H
YAMAHA 1998–DATE 40–50 HP HC4645H See Note 2
1998–DATE 60 HP HC4645H See Note 3
1986–DATE 70–90 HP HC4645H See Note 1
1997–DATE 80–150 HP 4-Stroke HC4645H
2000–DATE 25–60 HP 4-Stroke HC4648H See Note 1
2010–DATE 70HP 4-Stroke HC4648H
1997–2013 115A 4-STROKE HC4658H
2014-DATE 115B 4-STROKE HC4645H
YANMAR 1990–DATE 27–36 HP HC4645H

Notes
1. Requires Spacer kit part # HO5090
2. Engine clamp brackets must be cut or ground, and the engine through bolted onto the transom, or interference will occur, restricting engine trim and tilt.
3. Steering hook Yamaha Part # 63D-48511-00-4D must be installed
4. Cylinder HC4645 may be used in these applications. The pivot plate will need to be flipped before installation.
Instructions provided with Owner’s Manual.
5. Johnson 115 HP 2-Stroke engines, require the pivot plate to be flipped. See Note #4.

BAYSTAR CYLINDER PIVOT PLATE

HC4645H compact cylinder is included in the BayStar steering kits. This cylinder can be converted to HC4658H by following instructions included with the product. If your engine requires use of a cylinder other than HC4645H or HC4658H, please refer to the figure below for the appropriate replacement pivot plate, which must be purchased separately.
