Description
Lofrans Tigres 1500W 12V/24V Horizontal Electric Windlass LW415AN
High-Performance Horizontal Windlass with Reversing Motor & Manual Override
The Lofrans Tigres Windlass is one of the most trusted and recognizable horizontal windlasses in the marine industry, known for its reliability, durability, and user-friendly design. Featuring a powerful reversible motor, the Tigres allows you to deploy and retrieve your anchor electrically, while also providing a manual override option for emergencies or backup use.
Crafted from a marine-grade anodized aluminum alloy, the Tigres is built to withstand harsh saltwater conditions. Its separate capstan and gypsy allow for independent rope and chain handling, while its sleek above-deck housing, top-mounted snubbing cleat, and oil sight glass add convenience, style, and ease of use.
Key Features & Benefits
✔ Horizontal Windlass Design – Compact and traditional look with above-deck motor housing for easy access and installation.
✔ Reversing Motor for Power-Up & Power-Down – Allows full electric control of anchoring operations.
✔ Emergency Manual Override – Built-in manual release mode with included handle provides peace of mind in power-loss situations.
✔ Independent Gypsy and Drum Operation – Enables simultaneous rope and chain management; handles rope up to 3/4".
✔ Anodized Marine Aluminum Housing – Durable, corrosion-resistant, and hand-finished for long-lasting aesthetics.
✔ Sight Glass for Oil Level – Quickly check oil level without disassembly, simplifying maintenance.
✔ Top-Mounted Snubbing Cleat – Built-in cleat on deck offers secure chain management and added convenience.
✔ Available Gypsy Options for Different Chain Types – Models available for HT, BBB, and PC chain sizes (5/16” & 3/8”).
✔ Automatic Free Fall (Optional) – Upgrade available for hands-free deployment.
✔ IP67 Motor Protection – Keeps internal components sealed and protected in marine environments.
Specifications
| Specification | 12V | 24V |
|---|---|---|
| Line Speed @ Working Load | 14 m/min (46 ft/min) | 16 m/min (52 ft/min) |
| Max Line Speed | 33 m/min (108 ft/min) | 33 m/min (108 ft/min) |
| Maximum Pull | 1350 kg (2,976 lbs) | 1400 kg (3,086 lbs) |
| Working Load | 190 kg (419 lbs) | 195 kg (430 lbs) |
| Amps @ Working Load | 160A | 90A |
| Motor Power | 1500W Series-Wound | 1500W Series-Wound |
| Weight | 28 kg (61.7 lbs) | 28 kg (61.7 lbs) |
Model Options & Gypsy Types
| Part # | Voltage | Chain Type |
|---|---|---|
| LW415AN-5/16 | 12V | 5/16" HT |
| LW415AN-3/8B | 12V | 3/8" BBB |
| LW415AN-3/8P | 12V | 3/8" PC/HT |
| LW415AN/1-5/16 | 24V | 5/16" HT |
| LW415AN/1-3/8B | 24V | 3/8" BBB |
| LW415AN/1-3/8P | 24V | 3/8" PC/HT |
Standard Equipment Included
- Lofrans Tigres Windlass
- Watertight Control Box
- (2) Footswitches
- Chainwheel with Manual Override
- Manual Emergency Handle
- Top-Mounted Cleat
How to Choose Chainwheel (Gypsy)
- Lofrans Chainwheel Chart
- Your chain will be marked with BBB or HT
What Else to Consider When Buying
- AutoAnchor 570 Wireless Anchor Rod Counter and Control Kit
- Windlass Handheld remotes
- Windlass Circuit Breaker
- Windlass Chainstoppers
- LW415AN Maintenance Kit
Downloads & Resources
Why Choose the Lofrans Tigres Windlass?
With its proven reliability, robust build, and intuitive design, the Lofrans Tigres Windlass continues to be a top choice for boaters worldwide. Its horizontal configuration, reversible electric motor, and manual backup make it both powerful and versatile. Whether outfitting a new vessel or replacing an older unit, the Tigres offers smooth, dependable anchoring in all conditions.
Rely on the Lofrans Tigres for serious anchoring power and seamless on-deck performance.
Questions?
- Tech Support: Tech Support Page
- Check Stock: Stock Inquiry Page
- Request a Shipping Quote: Request Quote Page
- No Sales Tax on Purchases Outside of California
- Buy Now Pay Later with Affirm or PayPal Pay Later
- FREE Ground Shipping to the Lower 48 States
- Distributed by Imtra in the USA
- Seatech Marine Products, Inc. is an authorized dealer, and service center for Lofrans Windlasses
International, USVI, Puerto Rican, Hawaiian & Alaskan Customers: We Ship Worldwide and USPS, Shipping Cost May Quote Too High on Our Website, Contact Us for A Quote.
Replacement part information
Keep the original part number LW415AN when checking compatibility. The supplier identifies the following replacement references:
Replacement choice can depend on size, voltage, system version or additional components. Confirm compatibility before ordering.
