NEXTGEN UCM3-9.5 9.5kw Ultra Compact Marine Generator
The Next Generation 9.5KW Generator is one of the lightest, most compact and efficient gen-sets in its class.
- Comes with or without an enclosure
- Comes with the option for Ignition Protection
- Mid speed operation provides low sound and vibration levels
- Super efficient three vortex combustions system provides greater power output and cleaner burring exhaust while reducing fuel consumption
- Compact size & light weight makes for an easy installation
- One side service provides east maintenance
- Ultra compact size and light-weight construction
To receive Special Pricing on this unit, please click on the Request Special Pricing form below.
Product Features:
- Cupro - Nickel Heat Exchanger
- Water cooled exhaust manifold
- Self priming sea water pump
- Stainless steel water cooled exhaust system
- Air Cleaner/intake silencer
- Oil pressure & water temperature safety shutdown
- Self tensioning drive system
- 12 volt electric fuel pump
- Extra resilient four point isolation mounts
- “Easy Drain” oil change kit
- Front side service
- Marine grade tinned wire
- Remote start panel with hour meter and harness
- 3 Year Limited Warranty
Product Specifications:
- Dimensions
- Without Enclosure 24" Long x 21" Wide x 22" High
- With Enclosure 27.5" Long x 23.5" Wide x 23" High
- Weight
- Without Enclosure 290lbs
- With Enclosure 330lbs
- Operating Speed: 2,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
- Output Volts: 120/240
- Output Amps: 80/40
- Output Watts: 9,500
- Vertical, Water Cooled 4 Cycle diesel engine
| Number of Cylinders | 3 |
| Bore x Stroke (In) | 2.83 x 2.90 |
| Displacement (Cu. In.) | 54.8 |
| SAE net intermittent (HP/rpm) | 21 @ 2800 RPM |
| Combustion System | Three Vortex |
| Compression Ratio | 23:1 |
| Fuel injection Pump Type | Bosch MD Mini Pump |
| Nozzle Type | Bosch “throttle” type |
| Cooling System | Fresh Water Heat Exchanger |
| Lubricating System | Forced w/filter |
| Fuel | #2 Diesel Fuel |
| Lubricating Oil | API Service CD or CE |
| Type | Vertical, Water Cooled 4 Cycle diesel engine |
| Lubricating Oil Capacity | 4.0 U.S. Quarts |
| Starting System | 12V Battery |
| Charging System | 40 AMP (Optional) |
| Fuel Line Diameter | 5/16" |
| Return Line Diameter | 1/4" |
| Raw Water Diameter | 5/8" |
| Exhaust Diameter | 2" |
Optional upgrades:
- Ignition Protection Certification
- Fiberglass 3 piece sound enclosure
- Full instrumentation panel
- 20' or 30' Wire Harness
Downloads & Resources:
- NextGen 9.5 Generator Brochure [PDF]
- Tech Support: View Our Tech Support Page
