Description
KE Controls by NHK MEC
U.S. Sales & Support — Seatech Marine Products
NM2447-00 KE-6/7+ Control Unit
The NHK MEC NM2447-00 is the shared KE6+/KE7+ control-unit reference. KE6+ uses mechanical shift with electronic throttle; KE7+ uses electronic shift with mechanical throttle. The unit must be configured for the installed engine and gearbox.
Not sure which KE system fits your boat? Get help from our team.
When this part is useful
A replacement control unit must match the installed control family, supply and engine-interface arrangement. A change of system generation may require other components and setup changes.
Connection and installation planning
- A compatible control head, the specified harnesses and the engine-side components in the applicable wiring diagram.
- Follow the manual for settings, start-in-gear protection wiring and the engine/gearbox connections.
Downloads and Resources
FEATURED DOWNLOAD
NHK MEC Electronic Engine Controls Brochure
An overview of NHK MEC electronic engine controls, system choices and available options.
Download Brochure PDFNM2447-00 product questions
Is NM2447-00 interchangeable with every KE control unit?
No. Match the exact control family, unit code, electrical supply and engine-interface configuration.
Does NM2447-00 include the control head or actuator?
This listing is for the control unit. Other system components are specified and supplied separately.
System reference specifications
- Supply voltage: 9-32 V DC
- Actuator current: 16 A peak; 5 A average/typical at 49 N load under the manual’s nominal conditions
- Actuator current at stop/standby: 0.5 A or less
- Maximum operating thrust: 147 N
- Constraint load: 343 N
- Forward and reverse shift travel: 26 / 30 / 34 / 40 mm settings
- Electronic throttle outputs: 3-21 mA current; 0.2-4.53 V analog; 6-94% PWM at 500 Hz; or SAE J1939 CAN, selected for the engine
- CAN reference: 250 kbit/s; PGN 61443; CAN ID 0CF0 0331; throttle scale 0.4%/bit
- KE7+ mechanical throttle travel: 80 mm maximum
- KE7+ electronic shift contact capacity: 5 A maximum under nominal conditions
Help choosing the correct part
Send Seatech the NM2447-00 part number and details of your installed control system. Photos of the original component and its connections can help identify the correct replacement.
Request a system quote or contact Seatech Marine Products for parts selection and shipping information.
