Phasor Marine JD4-80.0KW Standard Series Boat Diesel Generator

(No reviews yet) Write a Review
SKU:
J4-80.0KW
UPC:
J4-80.0KW
Condition:
New
  • Phasor Marine JD4-80.0KW Standard Series Boat Diesel Generator
  • Phasor Marine JD4-80.0KW Standard Series Boat Diesel Generator
  • Phasor Marine J4-80.0KW Standard Series Boat Diesel Generator (J4-80.0KW)
For Pricing Use the "Request Special Pricing" Form Below
Built to Order - Typical Lead Time is 30 Days

Description

PHASOR MARINE 80.0kW Marine Diesel Generator - J4-80.0KW

The Phasor Marine 80.0Kw generator is one of the most popular marine diesel gensets for boats 70' - 100'. The unit outputs 223 amps on 208VAC Three Phase at a low 1,800 RPM operating speed; powered by a John Deere 4045AFM85 4 cylinder diesel engine.

To receive Special Pricing on this unit, please click on the Request Special Pricing form below.


Product Features:

  • Engine Features
    • John Deere 4045AFM85 - 4 Cylinder - 273 cu.in. displacement - Naturally Aspirated/IDI
    • Single Bearing Brushless Generator
    • Safety shutdown system for high coolant temp or low lube oil pressure
    • Air Intake Cleaner / Silencer
    • Stainless Steel Exhaust Elbow Cast
    • Stainless Steel 4-Point isolation mounts
    • Awl-Craft 2000 Urethane Finish - Long Lasting Gloss - Color Retention
  • Electrical Features
    • J-Can Electronic Panel
    • +/- 1% Solid-state voltage regulation
    • 12 Volt DC start / Battery charging alternator
  • Fuel System Features
    • Electric Fuel Transfer Pump
    • Secondary Racor Fuel Filter - 2 Micron
  • Oil System Features
    • Spin-on lube filter
    • Forged Brass Oil Drain Valve with Safety Lock
  • Cooling System Features
    • Direct drive sea water pump
    • Freshwater heat exchange cooling - zinc anode included

Product Specifications:

  • Dimensions:
    • (LxWxH) 65.0"x 32.0"x 38.0"
    • W/ Hard Sound Enclosure 68.5"x 38.0" x 41"
  • Weight: 2459lbs
  • Electric End: Newage
  • Operating Speed: 1,800 RPM (Less wear and tear compared to a 3,600RPM Genset)
  • Output Volts: 208VAC Three Phase
  • Output Amps: 223
  • Output Watts: 80,000
  • Fuel Consumption @ 50% Load: 4.3 GPH
  • Fuel Consumption @ 100% Load: 7.6 GPH
  • Phasor Marine 5 Year Limited Warranty

Optional upgrades:

  • Remote Panels
    • w/ 10 ft extension harness 101-0061
    • w/ 20 ft extension harness 101-0062
    • Remote Start/Stop W/O hour meter w/ 20ft harness 101-0092
    • Remote Start/Stop w/ Four Gauges and 20ft harness 101-0060
    • Relay Pak needs to be used with harnesses over 20ft 101-0333
  • Other Parts

Downloads & Resources:

View AllClose

Warranty Information

Seatech Marine Products is an authorized dealer for Phasor Generators. This has a limited 5 year warranty. Please see below under Downloads for full warranty information.
