Seastar HH5260-3 Rear Mount 1.4 Hydraulic Marine Helm Pump

Seastar HH5260-3 Rear Mount 1.4 Hydraulic Marine Helm Pump

The world's most popular hydraulic boat steering helm (HH52603) offers smooth, efficient no feedback steering for inboard and outboard applications.

Important Update: The HH5260-3 is being discontinued. For alternatives, view our Tech Support page with Dometic Seastars contact link:

• Tech Support: View Our Tech Support Page

Applications:

• Most Hydraulic Steering applications for inboard/sterndrive/outboard boats up to 50ft.
• Single outboard engine boats that travel up to 55MPH, for boats over 55MPH see SeaStar PRO Steering.
• Capable to be used in multiple stations.

Features:

• Top of dash fill point
• Compact helm
• Standard 3/4" tapered steering shaft
• Accepts wheels up to 28"
• Small 3.0" Hole cutout in dash

Specification:

• Rear Mount Installation
• 1.4 cubic inches
• 1000 PSI Relief Valve Settings

What Comes In The Box:

• HH5260-3 Helm Pump
• Mounting Hardware
• HF6004 Fitting Kit 2x ORB-5 90° Re-Positionable elbow fittings

SeaStar HH5260-3 Dimensions:

Downloads & Resources:

• SeaStar Boat Helm Pump Installation Manual [PDF]
• SeaStar Marine Hydraulic Steering Selection Guide [PDF]
• SeaStar Marine Steering Catalog [PDF]

CAUTIONS:

• Do NOT use teflon or loctite on the fittings.
• Do NOT try to install NPT fittings into helm pump as it may cause damage to the threads.
• The fluid cap must be in the uppermost position at ALL times.
• NEVER use brake fluid, only SeaStar Steering fluid or Mil Spec H5606 Fluid.

Installation Notes:

• The helm pump is packaged with re-positionable o-ring hose fittings (ORB).
• If a 20° mounting wedge is used, cut out dash as per mounting wedge template and mount helm directly to the 20° wedge.
• The helm may be mounted with the helm shaft horizontal, vertical, or any angle in between.
• Install the hose fittings before installing helm pump for ease of installation.

Related Items:

• HA5430H 1 Quart of SeaStar Fluid
• HA5438 Helm Bottle Filler Kit (this is not included with a helm pump)
• HH5261-3 SeaStar 1.7in³ rear mount helm pump
