Sidepower SH240/250TC-U11 Thruster Unit w/Parker Ultra motor 11cm3, max. thrust 240kg/528lbs

(No reviews yet) Write a Review
SKU:
SH240/250TC-U11
Condition:
New
$0.00
Typically Ships in 1-2 Business Days

Description

Side-Power SH240 Hydraulic Thruster with Parker Ultra Motor 11cm3, Max. Thrust 240kg/528lbs, Sealed Gearleg, Twin Counter Rotating 5-Bladed Q-Props

Side-Power's SH240 hydraulic thruster features twin counter rotating five bladed Q-Props, maximizing thrust from less hydraulic power.  The thruster produces 528 lbs. of thrust at 100% performance. Side-Power hydraulic thrusters can be purchased as part of a complete hydraulic system.

A complete Side-Power engineered system allows full proportional control of the thruster and unlimited run time, all based on the S-Link plug and play system.  Learn more about Side-Power hydraulic thruster systems.  Contact your local Side-Power representative for a system tailored to your needs.



Features & Benefits

  • Wide range of hydraulic motor sizes and types to optimize performance of the thruster unit
  • Unlimited run time at any thrust level, including max thrust
  • Reduced long term maintenance when compared to DC or AC thrusters
  • Improved maaximum thrust based on tunnel size
  • Total integration into any hydraulic system or supplied as part of a Side-Power engineered system

Performance

  • Propulsion technology know-how, maximizing amount of thrust from the system
  • Lightweight composite propellers reduce work needed to get up to speed and stop rotation
  • Streamlined gear housing, reducing turbulence in the tunnel and maximizing flow

Installation

  • Compact size to reduce the amount of interior volume needed
  • Simple Plug and Play wiring
  • Easily accessible hose connections
  • Fast and safe propeller mounting with lock nut
  • GRP and composite bolt-on stern thruster tunnel kits pre-drilled for ease of installation
  • Easy access zinc anodes allow quick and simple changing
  • Sealed gearleg so no messy oil fill-ups needed during installation

Safety and Reliability

  • Mechanical protection of drive gear through flexible coupling between gearleg and motor
  • Control panels have child-safe On system and timed shut down from last use
  • 2 year limited warranty
Light Duty Thrust up to 528 lbs (240 kg)
Heavy Duty Thrust up to 440 lbs (200 kg)
Typical Boat Size 42-75' (13-23m)
Tunnel Diameter 9.83" (250mm)
Propulsion System Twin Counter Rotating
Hydraulic Power 20hp(14.9kW)
Motor Size 11cm³ (0.67 in.³)
Manufacturer Side-Power
Pump Output 22.7hp(16.9kW)
Required Pressure 291bar(4221psi)
Required Flow 35lpm(9.2gpm)
Min Depth to Top of Tunnel 4.92" (125mm)
Min Depth to Center of Tunnel 9.84" (250mm)
