Zipwake 600 Series S ZW2011147 Trim Control System Kit

Zipwake Box 600 Series S ZW2011147 Dynamic Trim Control System Kit

Offered by Seatech Marine Products, Zipwake is an economical Dynamic Trim control System. Zipwake Series S KB600-S phases out the trim issues of planing & semi-planing boats ranging from 20-50 feet. Zipwake heightens fuel economy, comfort, performance & safety as you accelerate, turn and run in a seaway. The kit includes everything you'll need to install your new Zipwake system. You can further your speed and control with up to two additional pairs of interceptors.

Features:

• Fully automatic and active trim control system.
• Built-in GPS, 3D-Gyro, and 3D-Accelerometer in each control panel.
• Ideal for boats ranging from 20-50 feet (6-15 meters). See Series E for boats 50-100 Feet.
• 5-10 times faster than conventional trim tab systems.
• Minimizes wave resistance and reduces fuel consumption by 10-12%
• Allows system integration for external devices through the NMEA 2000 network.

Includes:

• (2) Interceptors. Width: 600mm
• (1) 3m Cable & Cable Covers
• (1) Distribution Unit with 4m power cable
• (1) Control Panel with 7m standard cable
• (1) Extension cable

Specifications:

• Certified for CE & FCC
• Max Boat Speed is 60 knots
• Blade stroke is 1.2" or 30mm
• Blade Rate is 0.8 in/s or 20mm/s
• The Thru Hull Cable Fitting can be Concealed or Above the Waterline
• Servo Actuator is SU-S
• The Cable Material is PUR
• The Cable Length is 10 feet or 3 meters, extendable up to 20 feet or 6 meters
• The Connector is M12 5-pin Circular, the Diameter is 0.57" or 14.5mm
• The Voltage is 12-32VDC
• Power Consumption max is 25W
• Ingress Protection is IP68, 15' or 5 meters
• The Operating Temperature ranges from 32F to 104F or 0C to 40C
• The Storage Temperature ranges from -40F to 194F or -40C to 90C

Not sure what Zipwake System you need?

Zipwake Kit size is determined by many factors including: the type of boat you have, the length, and the size of the back of your vessel among other details. Fill out our questionnaire below and receive a determination by a Zipwake tech.

1. Fill out the questionnaire here: Zipwake Questionnaire
2. Send the PDF along with a photo of the aft of your vessel (above the waterline) to info@imtra.com
3. Circle back around to purchase the kit Imtra recommends, use our Request Special Pricing form.

Learn more about Zipwake:

• Zipwake Dynamic Trim Control System

Downloads:

• Zipwake Series S Brochure
• Installation Guide PDF
• Zipwake Trouble Shooting Guide
• Zipwake Series S Operator's Manual

Also available in:

• 300mm (11.81") ZW2011145
• 300mm Chine (11.81") ZW2011732
• 450mm (17.72") ZW2011146
• 450mm Chine (17.72") ZW2011733
• 600mm (23.62") ZW2011147
• 750mm (29.53") ZW2011148

E Series for boats in length of 50-100 feet:

• 600mm (23.62") ZW2012011
• 600mm Chine (23.62") ZW2012014
• 800mm (31.49") ZW2012012
• 1000mm (39.37") ZW2012013
